MGA Part Numbers - 2H1082
Gasket -cork -tank attachment
For all MGA (and early MGB)

PART NO.  SPL.PAGE  DESCRIPTION
ACB5468   15.D.3    Gasket cork -tank attachment -(sender unit, fuel tank, 1500)
ACB5468   TC.D.3    Gasket -tank attachment (cork) -(sender unit, fuel tank, Twin Cam)
2H1082    TC3.D.3   Gasket -tank attachment (cork) -(sender unit, fuel tank, Twin Cam)-
    correction was ACB5468
2H1082    16.D.3    Gasket -tank attachment (cork) -(sender unit, fuel tank,1600)-
    correction was ACB5468

The cork gasket is a nice part. The small holes should be slightly smaller than the screws, so you will push the screws through the gasket. When the screws are tightened, the gasket will squeeze thinner as the cork will constrict to seal around he screws, so fuel cannot leak through or past the screw threads.

Aftermarket rubber gaskets will invariably have clearance holes round the screws, so the gasket will not seal round the screws. Moss Motors prescribed fix for this is a set of six nylon washers to seal under the screw heads.
